Gday
Just saw this adjustment on the forks. What does it do?
It's an 82 CB900
Thanks for your time
Scott |
| |
|
|
|
Hondamax
Silver CB900F
Joined: Feb 02, 2006
Posts: 1492
Location: Great Broughton, Cumbria, UK
|
| Posted:
Fri Feb 12, 2016 10:29 am |
|
| scottx wrote: |
Gday
Just saw this adjustment on the forks. What does it do?
It's an 82 CB900
Thanks for your time
Scott |
Was there meant to be a picture or link?
Regards,
Max |
_________________
1979 900Fz (from new) - NC30 Single-sided Swingarm, CBR1000F Forks, Tokico 4-Pot Callipers, Hindle 4:1, 985cc, to be recomissioned
1981 1100Rb - Rider (may sell)
1982 1100Rc/Rd Bitza - Started
1984 VF1000R - Started
1979 900Fz - Stored |
|
|
|
thx113
Friend of the Board
Joined: Apr 23, 2005
Posts: 3522
Location: Western Australia
|
| Posted:
Fri Feb 12, 2016 10:37 am |
|
Mmmm, maybe a bit more information. |
_________________
Running 0.06mm to 0.09mm valve clearances since 1983 and proud of it.
CB750 FB
CB1100FD Super Boldor
VF1000RE x 2
VF1000RF
Black scooter (06 CBR1100XX)
Red scooter (94 VFR750FR)
CT110 Hyper Sport |
|
|
|
|
BlueThunder
Red CB1100F
Joined: Jun 12, 2006
Posts: 9256
Location: Sarasota, Florida
|
| Posted:
Fri Feb 12, 2016 5:03 pm |
|
|
|
|
scottx
Silver CB750F
Joined: May 15, 2012
Posts: 733
Location: Sydney Australia
|
| Posted:
Fri Feb 12, 2016 6:20 pm |
|
Sorry.
I tried posting Friday night from my phone. I reckon it will work now that I actually put the photo in.
Thanks |
| |
|
|
|
|
Stueecat
Hawk
Joined: Aug 17, 2013
Posts: 302
Location: Devon. UK
|
| Posted:
Fri Feb 12, 2016 6:36 pm |
|
Hi Scott.
The small brass turny screw at the bottom of the leg is for the anti-dive seting.
1 = weakest effect.
4 = strongest effect.
It is of questionable usefulness and doubtful you'll notice any difference between the settings, just make sure they're both set the same. |
_________________
1983 Red CB1100F2D (CDN)
1983 blue CB1100F (Euro) project currently in 327 boxes !! |
|
|
|
|
AMC49
Black CB900F
Joined: Jul 30, 2003
Posts: 1828
Location: Fort Worth, TX.
|
| Posted:
Mon Feb 15, 2016 6:55 am |
|
Only works at braking, why it seems to not have any effect. |
| |
|
|
|
|
DrOlds
Silver CB900F
Joined: Feb 23, 2008
Posts: 1241
Location: Watertown NY USA
|
| Posted:
Mon Feb 15, 2016 12:14 pm |
|
It affects the front fork compression during front brake application. It functions by trapping more fork oil below the lower fork bushing as the caliper deflects against it's rubber mounts. When our bikes were new it was quite noticeable and it was a like it or hate it scenario. When turned up the front suspension became harsh while braking heavily on bumpy pavement and (for me) it prevented front end dive while braking going into corners which is a useful tool to steepen the front fork rake & trail.
There are a few reasons it is no longer noticeable on the poster's bikes on this tread...The lower fork bushings are worn out, the rubber bushings on the calipers are dead worn - hard or the fork oil is shot. |
